N08800铁镍基合金焊管在弯管成型时的开裂原因

基金项目:

山西省自然科学基金（201801D121081）；山西省重点研发计划（201903D121092）

详细信息

Cracking Causes of N08800 Fe-Ni Base Alloy Welded Pipe During Bend Forming

1. State Key Laboratory for Advanced Stainless Steel Materials, Taiyuan Iron & Steel(Group) Co., Ltd., Taiyuan 030003, China;
2. Technology Center of Shanxi Taigang Stainless Steel Co., Ltd., Taiyuan 030003, China

摘要: N08800铁镍基合金焊管在实际弯管成型中，时而存在开裂问题。采用宏观观察、化学成分分析、力学性能试验、金相检验、微观分析等方法对焊管在弯管成型过程中的开裂产生原因进行了分析。结果表明：N08800铁镍基合金焊管的开裂均发生在焊缝处。焊接过程中产生的焊缝浮渣、焊缝缩孔是造成焊缝处成型开裂的主要原因。较大尺寸的焊接浮渣会在外力作用下形成凹坑，进一步发展造成开裂。
- N08800铁镍基合金 /
- 焊管 /
- 开裂 /
- 焊缝浮渣 /
- 焊缝缩孔
Abstract: The cracking problem of N08800 Fe-Ni alloy welded pipe were found in the actual bend froming process sometimes. The cracking causes in the bend forming process of welded pipe were analyzed by means of macroscopic observation, chemical composition analysis, mechanical property test, metallographic examination and microscopic analysis. The results show that the cracking of N08800 Fe-Ni base alloy welded pipe were all located in the weld. The weld slags and welding shrinkage cavities during welding were the main reasons for the weld cracking during forming. The larger welding slags formed pits under the action of external force and further development caused cracking.
- N08800 Fe-Ni base alloy /
- welded pipe /
- cracking /
- welding slag /
- welding shrinkage cavity

[1]	LUAN T C, ROGER E E, LYLE F A. Gaseous pretreatment of high-alloy steel used in ethylene furnaces:pretreatment of Incoloy 800[J].Industrial & Engineering Chemistry Research,2003,42(20):4741-4747.
[2]	赵彬.电热水器加热管研发项目质量控制方法研究[D].上海:上海交通大学,2008.
[3]	AUREL R, MIRCEA N, LAURENTIU R C, et al. Optimal design of heating elements sheathed with lncoloy superalloy 800[J].WSEAS Transactions on Applied and Theoretical Mechanics,2010,5(3):208-220.
[4]	JIANG E, WANG E, DENG A. Experimental research on solidification structure of alloy 800H by linear electromagnetic stirring[J].China Foundry,2014,11:475-480.
[5]	程学群,李晓刚,杜翠薇,等.不锈钢和镍基合金在高温高压醋酸溶液中的腐蚀行为[J].中国腐蚀与防护学报,2006,26(2):70-74.
[6]	MOSS T E, WAS G S. Dynamic strain aging of Nickel-base alloys 800H and 690[J].Metallurgical and Materials Transactions A——Physical Metallurgy and Materials Science,2013,43:3428-3431.
