锅炉高温过热器弯管的失效分析

详细信息

Failure Analysis of High Temperature Super-heater Bend for Boiler

摘要: 用显微组织、力学性能和扫描电镜等方法,分析了1 900 t/h超临界锅炉用TP347H高温过热器弯管在高温运行近1 000h下产生裂纹的原因,结果表明,TP347H奥氏体钢冷加工成形后未经过固溶处理,腐蚀敏感性增强.在高温及烟气、煤灰覆盖层等运行环境下,在综合应力的作用下,加速腐蚀过程,在弯头应力集中部位产生了晶间应力腐蚀裂纹.
- TP347H钢 /
- 冷加工成形 /
- 残余应力 /
- 晶间应力腐蚀
Abstract: Fracture analysis of U-type bend of TP347H tube in the high temperature super-heater of a 1 900 t/h boiler operated for less than 1 000 h was carried out by means of examinations of microstructune,mechanical properties and scanning electron microscopy.The corrosion sensibility of cold-formed TP347H steel increased because solution heat treatment was not performed and the bend was operated under the conditions of high temperature and ash deposits.Intergranular stress corrosion cracking occurred at the position of stress concentration.
- TP347H steel /
- cold forming /
- residual tensile stress /
- intergranular stress corrosion

[1]	ASTM SA213/213M-06a.Standard specification for seamless ferritic and austenitic alloy-steel boiler,superheater,and heat-exchanger tubes[S].
[2]	R H Jones,S M Bruemmer.Assessment of stress-corrosion cracking in a water-cooled ITER[R].PNL-SA-17076,Pacificc Northwest Laboratory,Rinchland:Washington,1989.
[3]	Briant C L.奥氏体不锈钢的晶界偏析及其对晶间腐蚀和应力腐蚀开裂的影响[J].管根笙译.国外金属热处理,1990,11(5):52-60.
[4]	S Bernard,Jr Covino,James H Russell,et al.The role of ash deposits in the high temperature corrosion of boiler tubes[C]//Corrosion 2003.Houston:NACE International,2001:3718-3730.
[5]	Bernard S,Covino Jr.High temperature corrosion research at the albany research center[DB/OL]. http://www.netl.doe.gov.
[6]	K Natesan,D J Baxter.Oxygen-sulfhr corrosion of metals in mixed-gas atmospheres[C]//Proc.3rd Berkeley Conf.on Corrosion-Erosion Wear of Materials at Elevated Temperatures.Houston,TX:NACE International,1986:67-86.
[7]	K Natesan,C Kraus.Corrosion performance of structural alloys in oxygen/sulfur/chlorine-containing environments[C]//Proc.12th Ann.Conf.on Fossil Energy Materials.Knoxville,1998:18-30.
[8]	郑晓红,赵翔,曹欣玉,等.过热器弯管段有限元分析剩余寿命[J].锅炉技术,2004,35(1):32-35.
[9]	徐方成,蒋家羚,林兴华,等.内压作用下弯管应力的实验研究[J].厦门大学学报(自然科学版),2000,39(5):617-621.
