Parameter Determination of Mooney-Rivlin Model and Finite Element Simulation of the Compression Deformation of Rubber Rail Fastener
-
摘要: 利用应力、应变的虚功方程确定了适用于小变形橡胶的应变能模型——Mooney-Rivlin模型的参数; 建立了橡胶扣件的三维模型, 通过Abaqus有限元软件模拟了扣件变形的位移和应力云图, 得到了力-位移曲线并进行了试验验证。结果表明: 通过确定的C10, C01参数模拟得到橡胶扣件的应力分布与扣件实际受力相符合, 最大压缩位移约为3 mm; 模拟得到的力-位移曲线与试验得到的基本吻合, Mooney-Rivlin模型可以用于模拟橡胶扣件的变形情况。Abstract: The parameters of the strain-energy model, namely Mooney-Rivlin model, which is suitable for a small deformation rubber, was determined by the virtual work equation of strains and stresses. The 3D model of the rubber fastener was established and the displacement and stress distributions were simulated by the finite element software of Abaqus. The force and displacement curve was also obtained and the simulation results were verified by the experiments. The results show that the stress distribution of the rubber fastener simulated with the determined parameters C10 and C01 coincided well with the real stress state. The maximum compressive displacement was about 3 mm. The simulated force-displacement curve was in accordance with that by experiment. The Mooney-Rivlin model can be used to analyze the deformation of the rubber fastener.
-
-
[1] 卜继玲, 黄友建.轨道车辆橡胶弹性元件设计计算方法［M］.北京: 中国铁道出版社,2010. [2] 于建华, 魏永涛.不可压缩超弹性材料的有限元应力分析［J］.西南交通大学学报,1998, 33 (1): 41-45. [3] 敏乾.列车用橡胶堆旁承的两种本构模型振动特性研究［J］.机械,2015,42(10): 30-33. [4] 黄建龙, 解广娟, 刘正伟.基于Mooney-Rivlin和Yeoh模型的超弹性橡胶材料有限元分析［J］.橡塑技术和装备, 2008, 34(12): 22-26. [5] 魏松, 徐明会, 黄承.一种橡胶隔振器的研制方法［J］.材料开发与应用, 2014, 29(2): 11-16. [6] 王伟, 邓涛, 赵树高.橡胶Mooney-Rivlin模型中材料常数确定［J］.特种橡胶制品, 2004, 18(4): 8-10. [7] 郑明军, 王文静, 陈政楠,等.橡胶Mooney-Rivlin模型力学性能常数的确定［J］.橡胶工业, 2003, 22(8): 462-465. [8] CARLONE P,PALAZZO G S.Finite element analysis of the thermoforming manufacturing process using the hyperelastic Mooney-Rivlin model［C］//Computational Science and Its Applications-ICCSA 2006.Heidelberg: Springer Berlin Heidelberg, 2006: 794-803. [9] 王立国, 吴化敏, 高震天.基于ANSYS14. 0的电力机车转向架用橡胶元件有限元分析研究［J］.铁道机车车辆, 2015, 35(z1): 32-38.
