    建筑钢结构用钢材硬度与强度之间的关系

    张树勋, 冯照平, 王浩, 崔萌, 王宁

    张树勋, 冯照平, 王浩, 崔萌, 王宁. 建筑钢结构用钢材硬度与强度之间的关系[J]. 理化检验-物理分册, 2021, 57(6): 27-33. DOI: 10.11973/lhjy-wl202106006
    引用本文: 张树勋, 冯照平, 王浩, 崔萌, 王宁. 建筑钢结构用钢材硬度与强度之间的关系[J]. 理化检验-物理分册, 2021, 57(6): 27-33. DOI: 10.11973/lhjy-wl202106006
    ZHANG Shuxun, FENG Zhaoping, WANG Hao, CUI Meng, WANG Ning. Relationship between Hardness and Strength of Steel Used for Construction Steel Structure[J]. PHYSICAL TESTING AND CHEMICAL ANALYSIS PART A:PHYSICAL TESTING, 2021, 57(6): 27-33. DOI: 10.11973/lhjy-wl202106006
    Citation: ZHANG Shuxun, FENG Zhaoping, WANG Hao, CUI Meng, WANG Ning. Relationship between Hardness and Strength of Steel Used for Construction Steel Structure[J]. PHYSICAL TESTING AND CHEMICAL ANALYSIS PART A:PHYSICAL TESTING, 2021, 57(6): 27-33. DOI: 10.11973/lhjy-wl202106006

    建筑钢结构用钢材硬度与强度之间的关系

    基金项目:

    徐州市科技局社会发展项目(KC19216)

    详细信息
      作者简介:

      张树勋(1976-),男,高级工程师,主要从事钢结构产品质量检测及建筑钢结构安全性检测工作,gjwjzx@163.com

    • 中图分类号: TU391

    Relationship between Hardness and Strength of Steel Used for Construction Steel Structure

    • 摘要: 通过回归分析方法研究了建筑钢结构用钢材硬度(洛氏硬度、维氏硬度和布氏硬度)与强度(上屈服强度和抗拉强度)之间的关系,给出了用硬度推算强度的换算公式及换算偏差,并与GB/T 33362-2016和GB/T 1172-1999进行了对比。结果表明:建筑钢结构用钢材的硬度与强度之间呈正相关关系,用布氏硬度换算的抗拉强度的相对偏差明显低于洛氏硬度和维氏硬度的。GB/T 1172-1999给出的用洛氏硬度换算的抗拉强度和维氏硬度换算的抗拉强度与试验结果较为接近。考虑现有便携式硬度检测仪器及样品处理设备,采用洛氏硬度和布氏硬度推算钢材强度在实际工程中具有可操作性。
      Abstract: The relationship between hardness (Rockwell hardness, Vickers hardness and Brinell hardness) and strength (upper yield strength and tensile strength) of steel used for construction steel structure was studied by regression analysis method, the conversion formula and conversion deviation of hardness calculation strength were given, and compared with GB/T 33362-2016 and GB/T 1172-1999. The results show that there was a positive correlation between hardness and strength of steel used for construction steel structure, and the relative deviation of tensile strength converted from Brinell hardness was obviously better than that of Rockwell hardness and Vickers hardness. The tensile strength value converted from Rockwell hardness and the tensile strength value converted from Vickers Hardness given in GB/T 1172-1999 was close to the test result. Considering the existing portable hardness test instruments and sample processing equipment, it was feasible to calculate the steel strength by Rockwell hardness and Brinell hardness in practical engineering.
    • [1] 刘殿忠, 王武刚. 钢材强度无损检测方法比较分析[J]. 四川建材,2016,42(1):68-69.
      [2] 沈保罗,李莉,岳昌林. 钢铁材料抗拉强度与硬度关系综述[J]. 现代铸铁,2012,32(1):93-96.
      [3] 刘波,黄晓艳. 国家标准《金属材料硬度值的换算》解读[J]. 铸造技术,2018,39(3):736-738.
    • 期刊类型引用(5)

      1. 林普润. 石化工程建设中Q355钢材现场判别方法的研究. 硫磷设计与粉体工程. 2024(02): 23-25+48+57-58 . 百度学术
      2. 唐晓芳,赵海生,段嘉荣,王松. Q355XG钢冷轧板屈服强度较低的原因. 热处理. 2024(04): 32-34 . 百度学术
      3. 贾海东,徐烈,曹俊,王昕,祖越,康红勃,马卫锋. 在役三通力学性能无损检测与评价方法研究. 油气田地面工程. 2023(02): 71-77 . 百度学术
      4. 岑风,胡显军,顾晔,张红宇. 小试样拉伸试验方法. 理化检验-物理分册. 2023(04): 1-3 . 本站查看
      5. 刘汉卿. 浅析钢结构中钢材的选用. 冶金与材料. 2022(04): 156-157 . 百度学术

      其他类型引用(2)

    计量
    • 文章访问数:  25
    • HTML全文浏览量:  2
    • PDF下载量:  6
    • 被引次数: 7
    出版历程
    • 收稿日期:  2021-03-14
    • 刊出日期:  2021-06-07
