X-cor夹层结构剪切强度的有限元分析

党旭丹; 史少杰; 肖军

X-cor夹层结构剪切强度的有限元分析

1.
河南工程学院机械工程系, 郑州 451191
2.
河南工程学院机械工程系2.会计学系, 郑州 451191
3.
南京航空航天大学材料科学与技术学院, 南京 210016

基金项目:

河南工程学院博士基金资助项目(D2010002)

详细信息

作者简介:
党旭丹(1979－), 女, 河南洛阳人, 讲师, 博士。

中图分类号: TB322
计量
- 文章访问数: 3
- HTML全文浏览量: 0
- PDF下载量: 0
出版历程
- 收稿日期: 2012-05-28
- 刊出日期: 2012-08-19

Finite Element Analysis of X-cor Sandwich′s Shear Strength

摘要

摘要: 利用有限元软件分析了X-cor夹层结构的剪切强度及失效机理, 提出了失效判据和材料刚度退化规则, 明确了X-cor夹层结构的失效过程和模式; 根据失效判据, 采用有限元模型中发生刚度退化的单元及其分布模拟失效类型及扩展路径, 说明了X-cor夹层结构的剪切失效机理。结果表明: 在剪切载荷下, 树脂区首先失效, 然后是Z-pin拔出面板、Z-pin被剪断及Z-pin屈曲多重失效模式并存; 有限元分析结果与试验数值吻合较好, 说明了失效判据和刚度退化规则选择的有效性。
- X-cor夹层结构 /
- 剪切强度 /
- Z-pin /
- 有限元 /
- 失效判据 /
- 退化规则
Abstract: The finite element software was used to analyze the shear strength and failure mechanism of X-cor sandwich structure. During the shear strength analysis, the failure criterion and materials stiffness degradation rules were proposed, and the failure process and modes of X-cor sandwich structure were also clarified. According to the failure criterion, the elements with stiffness degradation and their distributions in the finite element model were used to simulate the types and propagation path of the failure. And the failure mechanism of X-cor sandwich was explained. The results show that under shear load the resin regions fail first; and then the multiple failure modes of Z-pin pull-out from the face-sheet, Z-pin shear off and Z-pin buckling appeared. The finite element results were consistent well with the values of test result after comparison, which meant that the failure criterion and stiffness degradation rules were effective.
- X-cor sandwich /
- Shear strength /
- Z-pin /
- Finite element /
- Failure criterion /
- Degradation rule

HTML全文

参考文献(14)

[1]	李顺林, 王兴业.复合材料结构设计基础[M].武汉:武汉理工大学出版社, 1993:120-121.
[2]	李河清, 赵景丽, 张元明, 等.固化压力对夹层结构力学性能的影响[J].工程塑料应用, 2002, 30(6):16-18.
[3]	CARSTENSEN T C, KUNKEL E, MAGEE C.X-corTM advanced sandwich core material[C]//FALCONE A.International SAMPE Technical Conference Series.CA:Society of Advancement Material and Process Engineering, 2001:452-466.
[4]	MARASCO A I, CARTIé D D R, PARTRIDGE I K, et al.Mechanical properties balance in novel Z-pinned sandwich panels:out-of-plane properties[J].Composites Part A:Applied Science and Manufacturing, 2006, 37:295-302.
[5]	PARTRIDGE I K, CARTI D D R, BONNINGTON T.Manufacture and performance of Z-pinned composites[M].USA Florida Boca Raton:CRC Press, 2003:103-138.
[6]	CARTI D D, FLECK N A.The effect of pin reinforcement upon the through-thickness compressive strength of foam-cored sandwich panels[J].Composites Science and Technology, 2003, 63:2401-2409.
[7]	田旭, 肖军, 李勇.X-cor夹层结构试制与性能研究[J].飞机设计, 2004(3):22-25.
[8]	黄涛, 矫桂琼, 杜龙.X-cor增强泡沫夹层结构力学性能试验[J].航空学报, 2008, 29(6):1542-1549.
[9]	杜龙, 矫桂琼, 黄涛, 等.Z-pin增强对泡沫夹层结构弯曲和振动性能的影响[J].材料科学与工艺, 2009, 17(6):741-745.
[10]	郝继军, 张佐光, 张蕾, 等.Z-pin植入参数对X-cor夹层复合材料力学性能的影响[J].航空学报, 2008, 29(3):763-768.
[11]	全国纤维增强塑料标准化技术委员会秘书处.纤维增强塑料(玻璃钢)标准汇编[M].北京:中国标准出版社, 1998:349-549.
[12]	吴德隆, 沈怀荣.纺织结构复合材料的力学性能[M].长沙:国防科技大学出版社, 1998:83-89.
[13]	SUN H Y, QIAO X.Prediction of the mechanical properties of three-dimensionally braided composites[J].Composites Science and Technology, 2007, 57(6):623-629.
[14]	党旭丹, 肖军, 谭永刚, 等.X-cor夹层结构压缩强度模型改进与实验验证[J].航空动力学报, 2009, 24(12):2802-2807.
