Effect of w(Ti+B4C+C)/w(Ni60A) on Structure and Performance ofNickel-Based Composite Coating by Plasma Cladding
-
摘要: 以Ni60A合金粉、钛（Ti）粉、石墨（C）粉和B4C粉为原料，其中w（Ti+B4C+C）/w（Ni60A）（w为质量分数/%）分别为0：100，10：90，20：80，30：70，采用反应等离子熔覆技术在304不锈钢表面制备镍基复合涂层，研究了w（Ti+B4C+C）/w（Ni60A）对涂层成形性、显微组织、硬度和耐磨性能的影响。结果表明：添加Ti+B4C+C的镍基复合涂层与基体呈冶金结合，且主要由（Ni，Fe）、CrB、TiC和Cr3Si相组成；增大w（Ti+B4C+C）/w（Ni60A）会增加强化相析出量，降低成形性；CrB在涂层中下部呈灰黑色细长条状，在上部呈细小块状或棒状，TiC主要以细小颗粒弥散分布于涂层中；当w（Ti+B4C+C）/w（Ni60A）为20：80时，涂层综合性能较优，平均显微硬度最高（948 HV），磨痕截面面积约为纯Ni60A合金涂层的1/5；镍基复合涂层主要发生黏着磨损和氧化磨损。Abstract: With Ni60A alloy, Ti, graphite (C), and B4C powders as raw materials and adjusting w(Ti+B4C+C)/w(Ni60A) (w is mass fraction/%) to 0:100, 10:90, 20:80 and 30:70, nickel-based composite coatings were synthesized by reactive plasma cladding on surface of 304 stainless steel. The effects of w(Ti+B4C+C)/w(Ni60A) on the formability, microstructure, hardness and wear resistance of the coating were studied. The results show that the nickel-based composite coatings with Ti+B4C+C were metallurgically bonded to the substrate, and were mainly composed of (Ni, Fe), CrB, TiC and Cr3Si. Increasing w(Ti+B4C+C)/w(Ni60A) improved the precipitation of strengthening phases and decreased the formability. CrB dispersed in the middle and lower part of the coating in gray-black slender strip forms, while in the upper part in small block or rod forms. TiC dispersed in the coating in fine particle forms. When w(Ti+B4C+C)/w(Ni60A) was 20:80, the comprehensive performance of the coating was relatively good; the average microhardness was the highest (948 HV) and the cross-sectional area of the wear scar was about 1/5 that of the pure Ni60A alloy coating. Adhesive wear and oxidative wear mainly occurred in nickel-based composite coatings.
-
Keywords:
- reactive plasma cladding /
- nickel-based alloy coating /
- TiC /
- microhardness /
- wear resistance
-
-
[1] 张嗣伟.我国摩擦学工业应用的节约潜力巨大——谈我国摩擦学工业应用现状的调查[J].中国表面工程,2008,21(2):50-52. ZHANG S W.Enormous economy potential of tribology application in industry in China-On the survey of present status of tribology application in industry[J].China Surface Engineering,2008,21(2):50-52.
[2] 柳斌,朱森第.表面工程与《中国制造2025》[J].表面工程与再制造,2016,16(6):13-14. LIU B, ZHU S D.Surface engineering and "made in China 2025"[J].Surface Engineering & Remanufacturing,2016,16(6):13-14.
[3] JIN G, LI Y, XIAO Q, et al. Effect of magnetic field on properties and element distribution of Ni-based WC composite coatings[J]. Materials and Manufacturing Processes, 2016, 31(9):1253-1260.
[4] ZHANG W Y,WANG C M,SONG Q,et al.Influence of Cr content on the microstructure and electrochemical corrosion in plasma cladding Ni-Cr coatings[J].Metallurgical and Materials Transactions A,2019,50(11):5410-5420.
[5] GAO G J,LI K,CHEN W W,et al.Physical characteristics of plasma cladding Fe-Cr-Nb-Si-Mo alloy cladding layers on different substrates[J].Journal of Wuhan University of Technology (Mater Sci Ed),2020,35(4):820-824.
[6] NESPOR D,DENKENA B,GROVE T,et al.Surface topography after re-contouring of welded Ti-6Al-4V parts by means of 5-axis ball nose end milling[J].The International Journal of Advanced Manufacturing Technology,2016,85(5/6/7/8):1585-1602.
[7] WANG M Q,ZHOU Z H,WU L T,et al.Characterization and in situ formation mechanism of tungsten carbide reinforced Fe-based alloy coating by plasma cladding[J].International Journal of Minerals,Metallurgy,and Materials,2018,25(4):439-443.
[8] WANG Z X,QIAN L,YANG W T.Study of plasma cladding Ni-based compound powder layers on Q235 steel[J].Applied Mechanics and Materials,2012,174/175/176/177:219-222.
[9] 戴军,宋玮琦,张杰,等.热处理对等离子熔覆钴基涂层组织及性能的影响[J].热加工工艺,2015,44(22):194-196. DAI J,SONG W Q,ZHANG J,et al.Effect of heat treatment on microstructure and properties of Co-based coating by plasma cladding[J].Hot Working Technology,2015,44(22):194-196.
[10] GONG J X,LU J B,LIU Y.Microstructure analysis of TiC reinforced Ni-based composite coating by plasma cladding[J].Advanced Materials Research,2012,538/539/540/541:286-289.
[11] 程晨.TC4钛合金表面等离子熔覆Ni基复合涂层组织研究[D].贵阳:贵州大学,2018:25-35. CHENG C.Microstructure of plasma cladding Ni based composite coating on TC4 titanium alloy[D].Guiyang:Guizhou University,2018:25-35.
[12] 王大力,潘庆亮,毛志成,等.等离子熔覆石墨烯增强镍基碳化物复合涂层研究[J].机械制造文摘(焊接分册),2019(4):24-28. WANG D L,PAN Q L,MAO Z C,et al.Research on graphene reinforced nickel-based carbide composite coating by plasma cladding[J].Welding Digest of Machinery Manufacturing,2019(4):24-28.
[13] 江少群,王刚,吕长月.(Ti+B4C)/Fe901比对等离子熔覆铁基涂层结构及硬度的影响[J].表面技术,2017,46(9):26-31. JIANG S Q,WANG G,LYU C Y.Effect of (Ti+B4C)/Fe901 ratio on microstructure and microhardness of Fe-based coatings synthesized by plasma cladding[J].Surface Technology,2017,46(9):26-31.
[14] LI J,ZHANG X J,WANG H P,et al.Microstructure and mechanical properties of Ni-based composite coatings reinforced by in situ synthesized TiB2+TiC by laser cladding[J].International Journal of Minerals,Metallurgy,and Materials,2013,20(1):57-64.
[15] 王燕琳,陈斌,洪鑫,等.高速钢激光熔覆Ni基WC条纹表面的磨损特性[J].热加工工艺,2019,48(8):135-137. WANG Y L,CHEN B,HONG X,et al.Wear characteristic of laser cladded Ni-based WC stripe surface of high speed steel[J].Hot Working Technology,2019,48(8):135-137.
[16] 杨胶溪,张健全,常万庆,等. 激光熔覆WC/Ni基复合涂层高温滑动干摩擦磨损性能[J].材料工程,2016,44(6):110-116. YANG J X, ZHANG J Q, CHANG W Q, et al. High temperature dry sliding friction and wear performance of laser cladding WC/Ni composite coating[J]. Journal of Materials Engineering, 2016, 44(6):110-116.
