第 45 卷 第 2 期                          电力与能源
                    2024 年 4 月                                                                          267

                                                                                       DOI:10.11973/dlyny202402028



                           基于向量计算的母线保护负序电压闭锁


                                                  校验方案研究



                                      徐梓源,方           苏,李启本,沈            良,俞       玲

                                          (国网上海市电力公司松江供电公司,上海 201600)

                    摘   要:针对母线保护复合电压闭锁中负序闭锁电压校验的问题,基于向量计算法研究了母线保护负序电压
                    的分解和计算,并提出了一种母线保护负序电压闭锁的简化校验方法。通过只调整 B 和 C 相电压幅值,改变
                    负序电压的大小,同时使零序电压及相电压满足闭锁要求,且不发生抢动现象。通过搭建试验平台,对该校验
                    方案进行了验证。
                    关键词:母线保护;负序电压;校验方案;向量计算
                    作者简介:徐梓源(1991—),男,硕士,从事电力系统继电保护工作。
                    中图分类号:TM772    文献标志码:A    文章编号:2095-1256(2024)02-0267-03
                    Verification Scheme of Negative Sequence Voltage Blocking for Busbar Protection

                                               Based on Vector Computation



                                    XU Ziyuan,FANG Su,LI Qiben,SHEN Liang,YU Ling




                              (State Grid Songjiang Power Supply Company,SMEPC,Shanghai 201600,China)




                    Abstract:In order to solve the problem of negative-sequence blocking voltage verification in bus protection com⁃
                    plex voltage blocking,the decomposition and calculation of negative-sequence voltage of bus protection are stud⁃


                    ied based on vector calculation method,and a simplified verification method of negative-sequence voltage block⁃
                    ing  is  proposed.  By  adjusting  only  the  B  and  C  phase  voltage  amplitude,the  negative  sequence  voltage  is

                    changed,and the zero sequence voltage and phase voltage meet the locking requirement,and no snatch phenom⁃


                    enon occurs. The test platform is set up to verify the verification scheme.



                    Key words:busbar protection,negative sequence voltage,verification scheme,vector computation

                    近年来,随着电力系统继电保护水平的不断
                                                                 1 负序电压闭锁的向量计算
                提高,110 kV 及以上电压等级变电站的重要母线
                                                                 1.1 电压序分量的向量表示
                均依据相关规范要求配置了母线保护装置。为确
                                                                     依据电压序分量的定义,在三相电力系统中,
                保母线保护动作的可靠性和选择性,母线保护通
                                                                 正序、负序及零序电压与电压相量之间的变换关
                常配备了由相电压、零序电压及负序电压的逻辑
                                                                      [3]
                                                                 系如下 :
                                           [1]
                或门构成的复合电压闭锁元件 。
                                                                                              é ê ê  ·  ù ú ú
                    在母线保护复合电压闭锁的校验过程中,负                                   ê ê ê éU 0 ù ú ú ú ú  1 ê ê é1  1  1 ù ê ê  U A ú ú ú ú
                                                                                             ú ú
                                                                                             ú ê ê
                                                                          ê
                                                                                                ·
                                                                          ê
                                                                              ú ú
                                                                          ê ê
                序电压的生成可能会误触发相电压及零序电压的                                     êU 1 =  3 ê ê ê ê1  α  α 2 ú ú ú  ê ê U B ú ú  (1)
                                                                                              ê ê
                                                                          ë U 2 û  ë1  α 2  α û  ê ê  ·  ú ú
                                                         [2]
                开放条件,从而影响负序电压闭锁定值的校验 。                                                        ë  U C û
                                                                        ·   ·   ·
                本文基于向量计算,提出一种母线保护负序电压                            式中 U A ,U B ,U C ——某一时刻电力系统中三相
                闭锁校验方案,并通过试验予以验证。                                电压的向量; U 0, U 1, U 2——此刻的零序、正序和
