                         基于高频探地雷达的超深电力隧道工作井


                                         结构损伤检测方法研究



                         汤敏吉 ,王          玲 ,吴辰斌 ,张永康 ,周思鸣 ,唐亘跻 ,任怡睿                                1
                                                                             1
                                                                                        2
                                  1
                                            1
                                                       1
                                                                  1
                                          (1. 国网上海市电力公司电缆分公司,上海 200072;
                                                    2. 同济大学,上海 200092)
                    摘   要:软土地区超深电力隧道工作井承受着较大的水土压力和荷载,在经过长期服役后,往往会出现各类病
                    害如变形、裂缝、渗漏水等,而电力隧道工作井具有较复杂的水土环境与电磁干扰等不利因素,采用正常的巡
                    查手段很难在早期发现结构的损伤与病害,因而对结构的正常服役与安全带来了极大的挑战。以上海杨树浦
                    电厂越江隧道 1 号工作井为研究对象,采用同济自研的高频探地雷达对结构长期的渗漏进行了全面细致的检
                    查,并对雷达数据进行了去噪和解析,分析了产生结构病害的原因以及后续的封堵和修复措施。结果表明:采
                    用高频探地雷达能够较好地捕捉到地下结构的脱空腔体与地下水分布情况,给后期的维修指明了方向。本研
                    究还可为今后类似的结构病害检测提供借鉴。
                    关键词:电力隧道;超深工作井;高频探地雷达;结构损伤检测
                    作者简介:汤敏吉(1985—),男,工程师,从事高压电缆隧道运维工作。
                    中图分类号:TM855    文献标志码:A    文章编号:2095-1256(2024)02-0203-05
                Structural Damage Detection Method of Ultra-deep Electric Well of Power Tunnel Based

                                      On High Frequency Ground Penetrating Radar


                                TANG Minji ,WANG Ling ,WU Chenbin ,ZHANG Yongkang ,
                                                                                          1
                                                                       1
                                            1
                                                         1




                                                                     2
                                                        1
                                           ZHOU Siming , TANG Genji , REN Yirui  1
                                 (1.State Grid Shanghai Cable Company,SMEPC,Shanghai 200072,China;



                                             2.Tongji University,Shanghai 200092,China)



                    Abstract:Ultra-deep electric power wells of power cable in soft soil areas are subjected to large soil and water



                    pressures and loads,and after long-term service,various damages such as deformation,cracks,seepage and wa⁃

                    ter leakage often occur. However,electric power wells are faced with unfavorable factors such as complex soil and


                    water environment and electromagnetic interference,and it is difficult to detect structural damages early by nor⁃

                    mal  inspection  methods.  Therefore,the  normal  service  of  the  structure  and  the  safety  of  the  structure  have
                    brought  great  challenges.  Taking  the  No.  1  working  well  of  cross-river  tunnel  of  Yangshupu  Power  Plant  in
                    Shanghai as the research object,the high-frequency ground penetrating radar(GPR)developed by Tongji Univer⁃


                    sity was used to conduct a comprehensive and detailed inspection on the long-term leakage of the structure,de-


                    noising and analyzing the radar data,and analyzing the causes of the structural diseases as well as the subsequent
                    plugging and repair measures. The use of high frequency GPR can better capture the cavity and groundwater distri⁃


                    bution of underground structure,which points out the direction for later maintenance,and can provide reference
                    for similar structural damage detection in the future.

                    Key words:power cable,ultra-deep well,high frequency ground penetrating radar,structural damage detection



                    电力隧道工作井随着服役期的不断延长,在                          等。因此,需要对工作井进行长时间的监测和定
                地下岩土水气的作用下,会产生各种各样的损伤,                           期检测作业。
                如结构变形、开裂、渗漏水、接头张开、钢构件腐蚀                              关于此类问题,国内相关专家均进行了一定
