第 44 卷 第 6 期
电力与能源
622 2023 年 12 月
DOI:10.11973/dlyny202306013
分布式电源接入对配电网的影响分析
曹 亮,房 睿,张怡捷
(国网上海市电力公司金山供电公司,上海 200540)
摘 要:分布式电源接入配电网会改变电网原有的结构,介绍了分布式电源接入配电网的现状,并指出传统配
电网接入分布式电源,可能会引发一系列问题,如导致系统电压越线和潮流发生翻转;分布式电源运行时产生
的谐波进入配电网后,会导致电网的电能质量降低 ;系统发生短路故障时 ,故障电流可能通过分布式电源进
入邻近线路,导致保护装置误动作。提出了相应的解决措施,包括安装无功补偿装置、电力滤波器,合理选择
分布式电源接入的位置和接入的容量等,旨在提高系统稳定性和电能质量,避免潜在的故障和问题。
关键词:分布式电源;配电网;电能质量
作者简介:曹 亮(1986—),男,硕士,工程师,从事变电站二次设备维护运行工作。
中图分类号:TM421 文献标志码:A 文章编号:2095-1256(2023)06-0622-03
Influence of Distributed Power Generation Access on Distribution Network
CAO Liang,FANG Rui,ZHANG Yijie
(State Grid Jinshan Power Supply Company,SMEPC,Shanghai 200540,China)
Abstract:The access of distributed power to the distribution network will change the original structure of the
grid. This paper introduces the current situation of the distributed power connecting to the distribution network,
and points out that the traditional distribution network with distributed power assess will cause many problems,
such as the system voltage overrun and the power flow reversing. The harmonics generated during the operation
of distributed power supply will reduce the power quality of the grid when they enter the distribution network.
When a short-circuit fault occurs in the system, the fault current may enter the adjacent line through the
distributed power supply, resulting in misoperation of the protection device. The corresponding solutions are put
forward, including the installation of reactive power compensation device, power filter, and reasonable selection
of distributed power access location, and access capacity.
Key words:distributed power supply,distribution network,power quality
分布式电源通常由新能源构成,具有清洁、无 电网的项目逐渐增加,分布式电源靠近用户,能够
污染等特点,在我国实现“碳达峰”“碳中和”的进 快速地就地对用户供电,避免了电能在长距离传
程中具有重要意义。 输过程中的损耗。因此,分布式电源接入配电网
分布式电源接入配电网后,由于更加靠近用 具有良好的经济效益,同时还能够提高电网的供
户,因此可以降低电能传输过程中的损耗,提高经 电可靠性。
济效益。分布式电源接入配电网会增加电网中的 当前,传统配电网在设计时并没有考虑分布
电源数量,提高供电可靠性,但也会使电网结构复 式电源接入后对电网的影响,分布式电源接入配
杂化,影响电网中的电压分布、潮流方向和继电保 电网后,会增加电网中的电源数量,使电网原有
护 [1-3] 。因此,应加强对分布式电源接入配电网的 的结构发生变化,这会给电网的运行维护带来困
研究,提高系统的稳定性。 难。因此,在传统配电网接入分布式电源时,必
须综合考虑系统的电压分布、潮流变化、电能质
1 分布式电源接入配电网的现状
量、继电保护等关键问题,确保电网的安全稳定
随着新能源技术的发展,分布式电源接入配 运行。
